カーソル位置にインライン画像を挿入するマクロ
もちろん、ただ単にインライン画像を挿入するだけではありません。
仕様
- ダイアログボックスで画像を選択する。
- カーソル位置に挿入する。
- 画像用のスタイルを当てる
- 四方に枠線を施す
- 図表番号を付ける
実にこれだけのことが1クリックでできます。
ソースコード
リスト1
Option Explicit 'ファイルフィルタ用文字列' Private Const FILE_FILTER_TYPE As String = "すべての図" Private Const FILE_FILTER_EXTENTION As String = "*.emf;*.wmf;*.jpg;*.jpeg;*.jfif;*.jpe;*.png;*.bmp;*.dib;*.rle;*.gif;*.emz;*.wmz;*.pcz;*.tif;*.tiff;*.eps;*.pct;*.pict;*.wpg" Private m_FSO As Object 'エントリポイント' Public Sub InsertInlineShapeWithSettings() If Not InsertInlineShape(Selection.Range) Then Exit Sub Call ApplyInlineShapeSettingsMain End Sub '///インライン画像の四方を囲む' Private Sub SetBordersAround(ByVal a_InlineShape As InlineShape, _ Optional ByVal a_LineStyle As MsoLineStyle _ = msoLineSingle, _ Optional ByVal a_LineWeight As Single = 1#) Dim tgtLnFormat As LineFormat Set tgtLnFormat = a_InlineShape.Line With tgtLnFormat .Visible = msoTrue .Style = a_LineStyle .Weight = a_LineWeight End With End Sub 'インライン画像を挿入する' Private Function InsertInlineShape( _ ByVal a_Range As Range) As Boolean InsertInlineShape = False 'ファイル名の取得。' Dim tgtFilePath As String tgtFilePath = getInlineShapeFilePath 'ファイル名が取得出来なかったらFalse' If tgtFilePath = "" Then Exit Function Dim ilShp As InlineShape Set ilShp = a_Range.InlineShapes.AddPicture(tgtFilePath) ilShp.LockAspectRatio = msoTrue Call ilShp.Select InsertInlineShape = True End Function '画像を一つだけ選ばせ、ファイル名を取得する' Private Function getInlineShapeFilePath() As String Dim ret As String ret = "" Dim exDir As String If Not HasDocumentProperty("ExDirectory") Then Call AddDocumentProperty(a_PropName:="ExDirectory", _ a_PropType:=msoPropertyTypeString, _ a_DefaultValue:=ThisDocument.Path) End If If m_FSO Is Nothing Then Set m_FSO = CreateObject("Scripting.FileSystemObject") If Not m_FSO.FolderExists(exDir) Then exDir = ActiveDocument.Path End If exDir = ThisDocument.CustomDocumentProperties("ExDirectory").Value Dim fpDialog As FileDialog Set fpDialog = Application.FileDialog(msoFileDialogFilePicker) Dim hasSelected As Boolean With fpDialog 'ダイアログボックスのタイトルを設定' .Title = "画像を選択せよ" '複数選択の設定' .AllowMultiSelect = False 'デフォルト表示フォルダの設定' .InitialFileName = exDir '一旦ファイルフィルタをクリア' Call .Filters.Clear 'ファイルフィルタを作成' Call .Filters.Add(FILE_FILTER_TYPE, FILE_FILTER_EXTENTION) 'ボックスを表示して、選択が為されたかどうかを取得' hasSelected = .Show 'ファイル選択されていたら、ファイル名を取得' If hasSelected Then ret = .SelectedItems(1) '一つ目のファイルパスからフォルダパスを取得する' exDir = Left(ret, InStrRev(ret, "\")) '" '自作ドキュメントプロパティに、選択したファイルのあるフォルダのディレク' 'トリを書き込む' ThisDocument.CustomDocumentProperties("ExDirectory").Value = exDir End If '再度ファイルフィルタをクリア' Call .Filters.Clear End With '値の返却' getInlineShapeFilePath = ret End Function '新しい自作ドキュメントプロパティを追加する ' Private Function AddDocumentProperty( _ ByVal a_PropName As String, _ ByVal a_PropType As MsoDocProperties, _ ByVal a_DefaultValue As Variant) As Boolean AddDocumentProperty = True On Error GoTo HandleError 'すでに存在するドキュメントプロパティ名を使用すると、Falseを返す' 'つまり、上書きはしない。' Call ThisDocument.CustomDocumentProperties.Add(Name:=a_PropName, _ LinkToContent:=False, _ Type:=a_PropType, _ Value:=a_DefaultValue) Exit Function HandleError: AddDocumentProperty = False End Function '/// 自作ドキュメントプロパティを削除する ' Private Function DeleteDocumentProperty( _ ByVal a_PropName As String) As Boolean DeleteDocumentProperty = True On Error GoTo HandleError Call ThisDocument.CustomDocumentProperties.Item(a_PropName).Delete Exit Function HandleError: DeleteDocumentProperty = False End Function '指定した名前のドキュメントプロパティがあるかどうか' Private Function HasDocumentProperty( _ ByVal a_PropName As String) As Boolean HasDocumentProperty = True Dim cdp As DocumentProperty For Each cdp In ThisDocument.CustomDocumentProperties If cdp.Name = a_PropName Then Exit Function Next HasDocumentProperty = False End Function '選択中の画像に枠線を施す' Private Sub setBordersForFigure( _ Optional ByVal a_LineStyle As MsoLineStyle = msoLineSingle, _ Optional ByVal a_LineWeight As Single = 1#) Dim ilShp As InlineShape If Selection.Type = wdSelectionInlineShape Then If Selection.InlineShapes.Count = 0 Then Exit Sub Set ilShp = Selection.InlineShapes(1) Else Exit Sub End If Dim tgtLnFormat As LineFormat Set tgtLnFormat = ilShp.Line With tgtLnFormat .Visible = msoTrue .Style = a_LineStyle .Weight = a_LineWeight End With End Sub 'ドキュメントが、指定した名前のスタイルを持っているか判定する' Private Function HasStyle( _ ByVal a_Document As Document, _ ByVal a_StyleName As String) As Boolean HasStyle = True Dim st As Style For Each st In a_Document.Styles If st.NameLocal = a_StyleName Then Exit Function Next HasStyle = False End Function Private Sub CreateStyleForFigure1(ByVal a_Document As Document) '///「Cst図1」スタイルを作成するためだけのメソッド ///' Dim st As Style Set st = a_Document.Styles.Add("Cst図1") With st .Visibility = True .UnhideWhenUsed = True .QuickStyle = True .Priority = 1 .BaseStyle = "標準" .NextParagraphStyle = "図表番号" With .ParagraphFormat .Alignment = wdAlignParagraphCenter .LineUnitBefore = 0.5 End With End With End Sub '選択中の画像にスタイルを当てて枠線を施し、キャプションも付ける' Private Sub ApplyInlineShapeSettingsMain() Const STYLE_FOR_FIGURE_1 As String = "Cst図1" Dim tgtDoc As Document Set tgtDoc = ActiveDocument Dim ilShp As InlineShape If Selection.Type = wdSelectionInlineShape Then Set ilShp = Selection.InlineShapes(1) Else Exit Sub End If '`Cst図1`スタイルがなかったら作る。' If Not HasStyle(tgtDoc, STYLE_FOR_FIGURE_1) Then Call CreateStyleForFigure1(tgtDoc) End If Call applyInlineShapeSettings(STYLE_FOR_FIGURE_1, "図") End Sub 'インライン画像に枠線・スタイル・図表番号をセットする' Private Sub applyInlineShapeSettings( _ ByVal a_ParagraphStyleName As String, _ Optional ByVal a_LabelName As String, _ Optional ByVal a_CaptionPosition As WdCaptionPosition _ = wdCaptionPositionBelow, _ Optional ByVal a_LineStyle As MsoLineStyle _ = msoLineSingle, _ Optional ByVal a_LineWeight As Single = 1#) '### 行内の画像に段落スタイルと枠線と図表番号をセットする ###' '### 引数 a_ParagraphStyleName:段落スタイルの名前 ###' '### 引数 a_LabelName:ラベルの名前 ###' '### 引数 a_CaptionPosition:図表番号の位置 ###' '### 引数 a_LineStyle:枠線の種類 ###' '### 引数 a_LineWeight:枠線の太さ ###' '画像に枠線をセットする' Call setBordersForFigure(msoLineSingle) '段落スタイルを適用する' Selection.Style = a_ParagraphStyleName If a_LabelName = "" Then GoTo ComeHere '図表番号のラベルをセットする' Dim lblIndex As Long lblIndex = getCaptionLabelIndex(a_LabelName) Dim captLabels As CaptionLabels Set captLabels = Application.CaptionLabels '図表番号を挿入する' Call Selection.InsertCaption(Label:=captLabels(lblIndex), _ Position:=a_CaptionPosition) ComeHere: End Sub Private Sub SetCaption(Optional ByVal a_LabelName As String = "図", _ Optional ByVal a_Position As WdCaptionPosition = wdCaptionPositionBelow) '図表番号のラベルをセットする' Dim lblIndex As Long lblIndex = getCaptionLabelIndex(a_LabelName) Dim captLabels As CaptionLabels Set captLabels = Application.CaptionLabels '図表番号を挿入する' Call Selection.InsertCaption(Label:=captLabels(lblIndex), _ Position:=a_Position) End Sub '図表番号のインデックスを取得する' Private Function getCaptionLabelIndex( _ ByVal a_TgtLabelName As String) As Long '### 受けとったラベル名が CaptionLabelsコレクションの何番目にあ ###' '### るかを返す。コレクション内になかったら、新規追加してその番 ###' '### を返す。 ###' Dim ret As Long Dim captLabels As CaptionLabels Set captLabels = Application.CaptionLabels Dim i As Long For i = 1 To captLabels.Count If captLabels(i) = a_TgtLabelName Then ret = i GoTo ReturnValue End If Next Call captLabels.Add(a_TgtLabelName) ret = captLabels.Count ReturnValue: getCaptionLabelIndex = ret End Function
上記コードをまるごとNormal.dotm
の標準モジュールに貼り付けて、InsertInlineShapeWithSettings
をクイック アクセス ツール バーに登録します。
図に当てるスタイルについては、Cst図1
という名前で決め打ちにしてあります。(めんどくさいので。)
おわりに
画像を挿入して、枠線を施して、図表番号を入れて……という作業は、地味にめんどくさいので、1クリックで画像選択ダイアログが出てきて、画像を選択(ダブルクリック)したらあとは勝手に枠線、スタイル当て、図表番号挿入までやってくれるので、めんどくさい作業が最短3クリックでできるようになります。
ずいぶん前に作ったマクロなので、もしかしたら動きが変なところがあるかも知れません。テキトーに直して使ってください。
